WS2812 IC LED Pixel Strip Light DC5V RGB Full Color Programmable

WS2812 IC LED Pixel Strip Light DC5V RGB Full Color Programmable

WS2812 IC LED Pixel Strip Light DC5V RGB Full Color Programmable
  • WS2812 IC LED Pixel Strip Light DC5V RGB Full Color Programmable
  • WS2812 IC LED Pixel Strip Light DC5V RGB Full Color Programmable
Product Details:
Place of Origin: China
Certification: ce
Model Number: Pixel strip
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: 500m/box
Delivery Time: 3-10days
Payment Terms: T/T
Supply Ability: 10000pcs/month
Contact Now
Detailed Product Description
Input Voltage(v): DC5V Led Light Source: SMD5050
Emitting Color: Changeable Led Quantity: 30/60/144leds/m
Ip Rating: IP20/IP65/IP67 Pcb Color: White PCB / Black PCB
High Light:

LED Pixel Strip Light DC5V

,

LED Pixel Strip Light Programmable

,

Full Color pixel led ws2812 strip

WS2812 IC Pixel Strip Light DC5V RGB Full Color Strip LED Magic Color Light

WS2812 LED programmable changing dynamic mode strip light.



Attention.
Must use DC5V power supply and LED controller to control WS2812 light bar
There are solder joints every 0.5m, please note!
PCB color: white PCB; black PCB

Protection grade.
(1) IP30 --- not waterproof for indoor use
(2) IP65 --- silicone coated, easy to cut, outdoor use
(3) IP67 --- silicone tube, need to reseal after cutting, outdoor use



Product parameter:
(1) working voltage: DC 5V
(2) LED source: SMD 5050 RGB
(3) LED chip: Epistar
(4) LED qty: 30/60 LEDs / M
(5) IC qty: 10/20 pcs / M
(6) power: 9 / 18 W / M
(7) gray scale: 256 / color
(8) cuttable: 3 leds / cut-out (external 2811 ic, 1 ic control 3 LEDs)
(9) beam angle: 120 °
(10) color mode: 133 patterns and 100 speeds
(11) size: 5000mm x 10mm x 2.4mm
(12) packing: 5m / roll 12v ws2811 rgb strip + 3 pin connector
(13) warranty: 1 years


Features:
(1) Easy back installation for flexible PCB (IP30, IP65) 3M adhesive tape.
(2) energy saving and environmental protection.
(3) high brightness 5050 SMD LED light strip.
(4) solid state, high shock or vibration resistance.
(5) low power consumption, high density.
(6) Match with RGB controller and power supplier system.
(7) wide viewing angle.
(8) Available in a variety of single and RGB colors.





Input Voltage(v): DC5V Led Light Source: SMD5050
Emitting Color: Changeable Led Quantity: 30/60/144leds/m
Ip Rating: IP20/IP65/IP67 Pcb Color: White PCB / Black PCB




Easy to install, Each LED lamp can be arbitrarily cut, good flexibility, easy installation, arbitrary bend Dream color lighting,
Match use controller can appear colorful curtain-up / flow water / raindrop / jump flash and so on hundreds of lighting effects,
You can also edit the animation effect with Coreldraw / Flash / LedEdit software. City lighting project, entertainment and
entertainment places lighting.


WS2812 IC LED Pixel Strip Light DC5V RGB Full Color Programmable 0

WS2812 IC LED Pixel Strip Light DC5V RGB Full Color Programmable 1WS2812 IC LED Pixel Strip Light DC5V RGB Full Color Programmable 2
